Electric Rolling Shutter Motor

Name: Electric Rolling Shutter Motor
Brand: KALPANA ENGINEERING WORKS

Get a Price/Quote

MOQ : 1 Unit

Electric Rolling Shutter Motor Specification

Product Type
Electric Rolling Shutter Motor

Material
Metal (Aluminum/Steel Body)

Opening Pattern
Rolling

Insulation
Class B/C Insulation

Operating Mode
Remote/Manual Switch

Color
Grey/Black

Quantity
1 Unit

Protection Grade
IP44

Motor Power
370W - 600W (Depending on Model)

Noise Level
50 dB

Operating Temperature
-10C to +50C

Application
Commercial, Industrial, Residential Shutters

Rated Voltage
220-240V AC, 50Hz

Mounting Type
Horizontal

Control System
Wireless Remote / Manual Key Switch

Limit Switch Type
Mechanical/Auto Reset

Maximum Lifting Capacity
Up to 800 Kg

Electric Rolling Shutter Motor Trade Information

Minimum Order Quantity
1 Unit

Payment Terms
Cheque

Supply Ability
Unit

Delivery Time
Week

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
As per requirement

Main Export Market(s)
North America, Eastern Europe, Western Europe, Africa, Central America, Australia, Middle East, South America, Asia

Main Domestic Market
All India

About Electric Rolling Shutter Motor

Kalpana steel works are the leading manufacture of excellent performing Electric Rolling Shutter Operator, Based in Bhavnagar, Gujarat, India. this sliding gate gear box is applied at rolling shutter automation and sliding gates. The Electric Rolling Shutter Operator offered by us can be availed with heavy duty motor for ensuring long performing life. Customers can avail Motorized Gear Box from us at affordable market price.

specifications and details for motorized sliding gate gear box

Width : 9
Length : 9
Height From Wall : 9
Reduction Ratio : 26:1
Output RPM : 55 RPM

Electric motor specifications for Sliding Gate Gearbox

Length : 9
Dia of Motor : 5
Shaft Dia : 14mm
RPM : 1440 RPM
Temperature : 40 to 60

Limit Switch Unit :

Externally fitted for easy setting
Size : 7 Length x 3 width
Two Micro Limit Switches (DVR-5) are used for Up-Down Limit.

Control Panel :

Two Contactors are Used (TC or LS)
Thermal relay used for protecting motor from overload

Technical Details :

Duel Operating Gearbox with automatic and manual operation.
Sturdy construction
Powder coated gearbox body provides attractive look and protects from sunlight
Can be operated manually in case of power failure
Gears made from EN-8 material
Worm wheel made from GM material
Long service life
Precisely machined parts ensures smooth functioning
Ideal for Heavy Rolling Shutters.
Worm-Worm Wheel is used for reducing heavy torque
Comes with self locking for safety
Available in different sizes with varied Motor Capacity, 1 HP , 1 HP with three phase.

Suitable for :

Sliding gates
Rolling shutters

Variety Available :

Rolling Shutter Gear Box
Sliding Gate Gear Box

Powerful Performance and Versatile Application

Ideal for various environments, this rolling shutter motor handles demanding loads, effortlessly lifting shutters up to 800 kg. Its adaptability makes it suitable for commercial, industrial, and residential doors, ensuring reliable security and access control across different settings. Multiple mounting and control options enhance installation flexibility.

Advanced Control Features for Enhanced Safety

The integrated wireless remote and manual key switch give users convenient and secure control over operations. The mechanical and auto-reset limit switches safeguard opening and closing limits, optimizing safety and extending motor lifespan. This smart control system streamlines daily usage, offering both ease and protection.

Built for Durability and Silent Operation

Constructed with a sturdy aluminum or steel body, the motor is engineered for longevity. Its insulation meets Class B/C standards, and the motor maintains a low noise level of 50 dB, making it ideal for settings where quiet functioning is essential. The IP44 rating ensures protection against dust and moisture, while efficient operation is guaranteed even in harsh temperatures.

FAQs of Electric Rolling Shutter Motor:

Q: How does the electric rolling shutter motor operate in different environments?

A: This motor is designed for commercial, industrial, and residential applications. Its wide operating temperature range from -10C to +50C and IP44 protection grade make it suitable for both indoor and outdoor locations, ensuring performance in varied climate conditions.

Q: What control options are available for managing the shutter operation?

A: You can operate the shutter using either a wireless remote control or a manual key switch. These dual control options offer both convenience and security, allowing users to choose the most suitable method for their needs.

Q: When should I select this shutter motor based on lifting capacity?

A: If your rolling shutter weighs up to 800 kg, this motor is an ideal fit. Its robust motor power ranging from 370W to 600W (depending on model) allows for efficient lifting and lowering of heavy shutters, making it suitable for high-usage environments.

Q: Where can this motor be mounted for optimal performance?

A: The motor is designed for horizontal mounting, providing stable and secure installation. This setup is compatible with rolling shutters in various applications, including shop entrances, warehouse doors, and residential garage doors.

Q: What safety features does this rolling shutter motor offer?

A: The motor includes a mechanical/auto-reset limit switch which prevents the shutter from overextending or retracting beyond its preset positions. This feature increases operational safety and helps protect the motor and shutter from damage during use.

Q: How can users benefit from its low noise level and strong insulation?

A: Operating at 50 dB, the motor ensures minimal noise, making it ideal for environments sensitive to sound. The Class B/C insulation safeguards the motors internal components, enhancing durability and performance in demanding conditions.

Q: What is the process for switching between remote and manual operation modes?

A: Switching between modes is seamless; users can operate the shutter via the remote for everyday convenience or use the manual key switch during power outages or emergencies, ensuring uninterrupted functionality.
